(1) Transmission System: Provide Volvo models for your choice,with strong power and good weather resistance.
(2)Transmission: The original imported Dana transmission, stable and efficienttransmission.
(3)Drive Axle: The truck adopts the original imported Kessler bridge and wet discbrake, which is specially designed
for heavy trucks and can meet the requirementsof continuous operation and maintenance free under harsh working
conditions.
(4)Hydraulic System: Adopt the high efficiency and oil saving hydraulic systemproduced by American park company.
Innovativeself-cleaning hydraulic cooling system design extends the time between oilchanges and reduces the total
cost of the machine.Adopt advanced technology such as load sensing, double pump convergent, high pressure and
small flow to save energy and reduce cost.
(5)Electronic Control System: The can bus system we selected comes from 3B6(Italia), which has high control accuracy
and can be updated online. This function can be extended and parameters can be modified. Intelligent loading security
system and fault diagnosissystem improve the maintainability of the system.
(6)High Strength Structural Elements: Heavy box chassis is the foundation ofdurable and high performance.
(7)Cabin: The elevated cabin and dual power suspension system ensure a comfortableoperating environment and low
noise and vibration.
Identification | Series | G Series | |||||||||
Model | CPCD200-VZ1-12ⅣG2 | CPCD250-VZ1-12ⅣG2 | CPCD280-VZ1-12ⅣG2 | CPCD300-VZ1-12ⅣG2 | CPCD320-VZ1-12ⅣG2 | CPCD350-VZ1-12Ⅳ | CPCD380-VD2-12Ⅳ | CPCD420-VD2-12Ⅳ | CPCD460-VD2-12Ⅳ | ||
Rated capacity | lb | 44092 | 55116 | 61729 | 66139 | 70548 | 77162 | 83776 | 92594 | 101413 | |
Load center | in | 47.2 | 47.2 | 47.2 | 47.2 | 47.2 | 47.2 | 47.2 | 47.2 | 47.2 | |
Dimensions | Overall height(overhead guard) | in | 149 | 149 | 152 | 152 | 152 | 152 | 176 | 172 | 172 |
Overall length(with fork/without fork) | in | 344 | 344 | 360 | 360 | 360 | 360 | 389 | 408 | 408 | |
Overall width (single Tyre) | in | 120 | 120 | 136 | 136 | 136 | 136 | 162 | 162 | 162 | |
Min.turning radius(exterior)(A single tyre is the same double tires) | in | 233 | 233 | 252 | 252 | 252 | 252 | 274 | 296 | 296 | |
Weight | Total weight | lb | 73193 | 80468 | 88185 | 92594 | 94799 | 101412 | 113758 | 120372 | 124781 |
Wheels,Chassis | Tyre size | in | 14.00-24 | 14.00-24 | 16.00-25 | 16.00-25 | 16.00-25 | 16.00-25 | 18.00-25 | 18.00-25 | 18.00-25 |
Performance | Max.traveling speed (Loaded/Unloaded) | mph | 15/16.1 | 15/16.1 | 14.3/15.5 | 14.3/15.5 | 14.3/15.5 | 14.3/15.5 | 13.7/15.2 | 13.7/15.2 | 13.7/15.2 |
Engine mode | VOLVO TAD871VE | VOLVO TAD1171VE | |||||||||
Engine rated power | HP/rpm | 248/2200 | 355/2100 | ||||||||
Engine rated torque | (ft*Ib)/rpm | 856/1350 | 1317/1316 | ||||||||
Emission standard | T4F | T4F | |||||||||
Transmission mode | ZF 211 | ZF 211 | ZF 211 | ZF 211 | ZF 211 | ZF 211 | DANA 36000 | DANA TE27 | DANA TE27 | ||
Drive axle mode | Kessler | Kessler | Kessler | Kessler | Kessler | Kessler | Kessler | Kessler | Kessler |
